4 portlu Fast Ethernet idarəolunmayan PoE switch
4 portlu Fast Ethernet idarəolunmayan PoE switch
Sorğu əsasında
Qiymət sorğusu- General
- Shell
Metal material, fan-free design
- Gross Weight1.20
- Net Weight0.555
- Dimension (L × H × D)217.6 mm × 103.35 mm × 27.8 mm (8.57” × 4.07” × 1.09”)
- Operating Temperature-10°C to 40°C (14°F to 104°F)
- Storage Temperature-40°C to 85 °C -40°F to 185°F)
- Operating Humidity5% to 95% (no condensation)
- Storage Humidity
5% to 95% (no condensation)
- Power Supply48 VDC, 1.35 A
- Power Consumption in Idle< 5 W
- Power Souce65 W
- Max. Power Consumption65 W
- PoE Power Supply
- PoE StandardPorts 1 to 8: IEEE 802.3af, IEEE 802.3at
- PoE Power Pin
Ports 1 to 4: Ethernet cables 1/2/3/6 and 4/5/7/8 provide power
supply simultaneously.
- PoE PortPorts 1 to 8
- Max. Port PowerPorts 1 to 8: 30 W
- PoE Power Budget60 W
- Network Parameters
- Port Number8 × 10/100Mbps PoE ports, and and 2 × Gigabit RJ45 ports
- Port TypeRJ45 port, full duplex, MDI/MDI-X adaptive
- StandardIEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z and IEEE 802.3ab
- Forwarding Mode
Store-and-forward switching
- Working ModeStandard mode (default), Extend mode
- Ports for Long-Distance TransmissionPorts 1 to 8
- MAC Address Table16 K
- Switching Capacity5.6 Gbps
- Packet Forwarding Rate4.1664 Mpps
- Internal Cache4 Mbits
- Dialing Function
- Long RangePorts 1 to 8: up to 250 m.
- Approval
- EMC
FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-
3-2: 2014, EN 61000-3-3: 2013, EN 55024: 2010 +A1: 2015); RCM
(AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016)
- Safety
UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CELVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013)
- Chemistry
CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC)
No 1907/2006)
