Hikvision DS-QAE1A80G1-VB

Artikul: 59843bfb2ca0

80W 2 Zonlu Şəbəkə Gücləndiricisi

Nominal güc: 80 W, 2 zona
Audio girişləri: USB/Bluetooth/MIC/RCA
İki zonada səs səviyyəsinin və məzmunun tənzimlənməsini dəstəkləyir
Cədvəl üzrə/canlı/təcili yayımı, siqnalizasiya əlaqələndirməsini və TTS-i dəstəkləyir

Bakıya – bu gün
Azərbaycan daxilində 1-2 gün

36 aya qədər
istehsalçıdan

Hikvision-un rəsmi distribyutoru

Avadanlıqların seçilməsi və qurulmasında köməklik

ədəd stokda

2 saata çatdırılma

Sorğu əsasında

Partnyorlar üçün qiymət

Endirim tələb edin

Mütəxəssis köməyi

Avadanlıq seçməkdə çətinlik çəkirsiniz?

Function
Audio Bit Rate
G.711ulaw（64 Kbps）/G.711alaw（64 Kbps）/MP3（128 Kbps）

Sampling bit width: 16 bits
Speech SynthesisLanguage Type: English, Russian, Spanish, Japanese, Thai, Portuguese (Brazil), Korean, French
Protection Functionshort circuit protection, overcurrent protection, over temperature protection, anti-static electricityprotection, surge protection, electrical shock protection

Network
Network ProtocolIPv4, HTTP, HTTPS , SSL/TLS , DNS,NTP, TCP, UDP, IGMP, ICMP, DHCP, ARP, SSH
Interface Protocol (API)ISAPI, ISUP, RTP

Interface
Alarm
1 alarm input

1 alarm output
Ethernet Interface1个RJ45 10 M/100 M adaptive Ethernet port
Local StorageBuilt-in 4 GB EMMC (Audio file storage is 1 GB.)
Audio In
MIC 1: -28 dBV, 2.57 KΩ, unbalanced, 6.35 mm jack, supports dynamic microphone connection

USB 2.0 × 1

RCA in 1-2:0 dBV, 5 KΩ, unbalance, RCA pin jack

Bluetooth
Audio Out
Constant Voltage Output × 2，100 V COM

RCA Out 1-2:0 dBV, 100 Ω, unbalance, RCA pin jack

RCA Cascading: support a cascade of up to 3 amplifiers
LED Indicator
Power indicator (solid white): the device is normally working

USB flash drive indicator (solid white): the device is in USB mode

Bluetooth indicator (solid blue): the device is in Bluetooth mode
Volume KnobMIC Volume Knob × 1，Partition 1 Volume Knob × 1，Partition 2 Volume Knob × 1
USB
USB 2.0/3.0.

File format: FAT32, maximum capacity: 128 GB.

FAT32 file system: maximum partition size: 128 GB, maximum file size: 4 GB.
Power InterfaceAperture size: Ø2.0 mm

General
MaterialPlastic
Language41 languages: English, French, Spanish, German, Italian, Japanese, Thai, Russian, Portuguese (Brazil), Arabic, Bulgarian, Czech, Danish, Greek, Spanish (Mexico), Estonian, Persian, Finnish, Hebrew, Croatian, Hungarian, Indonesian, Kazakh, Korean, Kirgiz, Lao, Lithuanian, Latvian, Dutch, Norwegian, Polish, Portuguese, Romanian, Slovak, Slovenian, Serbian, Swedish, Turkish, Ukrainian, Uzbek, Vietnamese
Dimension190.8 mm × 230.8 mm × 51.2 mm (7.48″ × 9.06″ × 2.01″)
Package Dimension362 mm × 280 mm × 100 mm (14.25″ × 11.02″ × 3.94″)
≈ 1496.2 g (3.3 lb.)
With Package Weight≈ 2456.2 g (5.4 lb.)
ColorWhite
Packing List
Device × 1

Power Adapter × 1

Power Cord × 1

Regulatory Compliance and Safety Information × 1
BluetoothBluetooth 5.0，10 m
Operating Temperature-10 °C to 55 °C (14 °F to 131 °F)
Operating Humidity＜90% (No condensation)
Power Consumption
Standby Consumption: 4.5 W

Annual Average Consumption: Max. Working Consumption: 90 W (based on the average playing time)
